Pentair Hydromatic HV200 Series Grinder Pumps

The Hydromatic HV200 Series grinder is engineered from the ground up in order to overcome the increased debris and higher pressure required in today's wastewater environment. It features a patented axial cutter design and semi-open impeller to effectively macerate challenging sewage solids into a fine slurry.

KEY FEATURES

  • Patented axial cutter technology
  • Advanced hydraulics
  • Legendary seal leak detection

Additional Features:

  • Cable Entry System
  • Oil-Filled Motor
  • Heat Sensor
  • Heavy 416 SST Shaft
  • Double Mechanical Shaft Seals
  • Seal Leak Probe
  • SST Semi-Open Impeller
  • Axial Cutter System
  • Lower Double Row Ball Bearings
  • Volute Case

WARRANTY

Pentair warrants its V and VR series grinders against defects in material and workmanship for a period of 24 months from the manufacturing date, or 36 months from the manufacturing date with the completion of a start-up report within 30 days of installation.

Size and Configure Hydromatic Pumps

Launch Encompass

Locate a distributor near you

View Locations

See In Action

Specifications

Capacities To:  31 gpm / 117.3 lpm
Heads To:  185 ft / 56.38 m
Liquids Handling:  Domestic raw sewage
Intermittent Liquid Temp.:  Up to 140 F / Up to 60 C
Winding Insulation Temp (Class F):  311 F / 155 C
Std. Third Party Approvals:  CSA
Acceptable pH Range:  6-9
Specific Gravity:  .9 - 1.1
Viscosity:  28 - 35 SSU
Discharge (Flange Dia.):  1 1/4 in / 31.75 mm
Minimum Sump Diameter:  Domestic raw sewage
- Simplex:  24 in / 61.0 cm
- Duplex:  36 in / 91.4 cm
