BODY CONSTRUCTION:  Class 30 Cast Iron
HORSEPOWER:  Available in 1-1/2, 2, OR 3 HP
MAXIMUM HEAD:  40'
MAXIMUM CAPACITY:  335 GPM (21.1 LPS) (3 HP)
FLOW at 10' LIFT:  300 GPM (using 2 HP as average)
SWITCH TYPE:  Control Panel Required
MINIMUM SUMP DIAMETER:  Simplex: 24" (609.6 mm)
DISCHARGE PIPE SIZE:  3" NPT vertical OR 3" flanged horizontal optional)
MAXIMUM SOLIDS HANDLING SIZE:  2.5" (63.5 mm)
AMP DRAW (full load):  HP and Voltage Dependent -- See Spec Sheets for Details
CORD LENGTH:  35' STW
VOLTAGE:  Available in 208-230V -phase OR 208-230V/460-575V 3-phase
MAXIMUM LIQUID TEMPERATURE:  140 F (60 C)
PHASE:  1-phase or 3-phase (voltage dependent)
IMPELLER:  Class 30 Cast Iron
