Pentair Sta-Rite HP Series Cast Iron High-Pressure Booster Pumps

Some of the most durable booster pumps available. The SignaSeal floating impeller design minimizes thrust loads allowing for continuous operation without damage to motor bearings, mechanical seal, or pump hydraulic components.

KEY FEATURES

  • Proven SignaSeal staging system utilizes a ceramic wear surface that dominates with 1st-in-class performance.
  • Superior sand-handling and thrust management staging system
  • Precision-molded acetal impellers for perfect balance. Ultra-smooth for highest performance and efficiency
  • Precision-molded diffusers offer superior performance with high resistance to corrosion and abrasion
  • Precision lapped and highly polished carbon-ceramic mechanical shaft seal with stainless steel parts guarantees continuous water lubrication
  • Superior motor winding insulation materials protect against excessive moisture and contaminants assuring prolonged motor life
  • Precision rotor is die-cast under high pressures for uniform performance and greater efficiency
  • All electrical components are protected from dirt, dust, and insects by a dustproof canopy which the ventilating air cannot contaminate

WARRANTY

Limited 1-year warranty

Explore purchase options available for this product.
Where to Buy

Performance Curves



Specifications

PERFORMANCE SERIES:  7 thru 30 GPM Series available
HORSEPOWER:  Available in 1/2 thru 3 HP
VOLTAGE:  Available in 115v / 230v or 208v-230v/460v, 60 Hz, 1-phase
NUMBER OF STAGES:  6 to 16 (model dependent)
INLET SIZE:  3/4" to 1-1/2" NPT (model dependent)
OUTLET SIZE:  3/4" to 1-1/2" NPT (model dependent)
MAXIMUM INLET PRESSURE:  80 PSI
MAXIMUM WORKING PRESSURE:  315 PSI
MAXIMUM SUCTION LIFT:  15 ft
MAXIMUM WATER TEMPERATURE:  Prolonged use with liquids above 140° F is not recommended
DISCHARGE MATERIAL:  Cast Iron
MOTOR ADAPTER & BASE:  Cast Iron
SHELL:  304 Stainless Steel
IMPELLER:  Acetal
DIFFUSER:  Polycarbonate
SHAFT:  304 Stainless Steel
O-RINGS:  Buna-N
MECHANICAL SEAL:  Carbon/ceramic, Buna-N
