Pentair Hypro Asymmetric Ultra Lo-Drift Ceramic 120˚ Spray Nozzles

Pentair Hypro Asymmetric Ultra Lo-Drift Ceramic spray nozzles feature extremely low-drift, twin air induction spray technology for optimized deposition and reduced spray drift at higher driving speeds

  • Ideal for high coverage applications of contact pesticides
  • High drift reduction over entire pressure range
  • Twin flat spray jet 30°/50° with asymmetrical spray angles and flow rates
  • Finer droplet spectrum to the front to drive direction for optimum wetting
Explore purchase options available for this product.
Where to Buy

Key Features

Asymmetric Ultra Lo-Drift Ceramic 120˚

Spray pattern imaging

Spray Pattern

High-speed imaging of spray pattern produced by the Pentair Hypro Asymmetric Ultra Lo-Drift Ceramic spray nozzles.

Spray pattern imaging

Spray Pattern

High-speed imaging of spray pattern produced by the Pentair Hypro Asymmetric Ultra Lo-Drift Ceramic spray nozzles.

Previous
Next
0101

Specifications

Common Use: Plant Health
Pattern: Tapered Flat Fan
Technology: Air Induction
Material: Ceramic
Spray Angle: Front 120˚ Back 90˚
Configuration: Tips, FastCap
Item #Nozzle SizeDroplet Size RangePressure RangeFlow Rate
Item #
AULDC120-02
Nozzle Size
02
Droplet Size Range
XC-M
Pressure Range
15-115 PSI
Flow Rate
0.12-0.34 GPM
Item #
AULDC120-025
Nozzle Size
025
Droplet Size Range
XC-M
Pressure Range
15-115 PSI
Flow Rate
0.15-0.43 GPM
Item #
AULDC120-03
Nozzle Size
03
Droplet Size Range
XC-M
Pressure Range
15-115 PSI
Flow Rate
0.18-0.51 GPH
Item #
AULDC120-04
Nozzle Size
04
Droplet Size Range
XC-M
Pressure Range
15-115 PSI
Flow Rate
0.24-0.68 GPM
Item #
AULDC120-05
Nozzle Size
05
Droplet Size Range
XC-M
Pressure Range
15-115 PSI
Flow Rate
0.30-0.85 GPM
Item #
AULDC120-06
Nozzle Size
06
Droplet Size Range
XC-M
Pressure Range
15-115 PSI
Flow Rate
0.36-1.00 GPM
Item #
AULDC120-08
Nozzle Size
08
Droplet Size Range
XC-M
Pressure Range
20-115 PSI
Flow Rate
0.59-1.4 GPM
