Pentair Hypro Lo-Drift Ceramic 90 & 120˚ Spray Nozzles

Pentair Hypro Lo-Drift Ceramic spray nozzles feature our pre-orifice design to provide a low-pressure chamber that increases droplet size and reduces production of fine spray droplets.

  • Reduced spray drift
  • Medium and coarse spray droplets for contact pesticide applications
  • Pre-orifice insert can be removed for cleaning
  • Ideal nozzle for both contact and systemic pesticide applications
Explore purchase options available for this product.
Where to Buy

Specifications

Common Use: Plant Health
Pattern: Tapered Flat Fan
Technology: Pre-orifice
Material: Ceramic
Spray Angle: 90˚, 120˚
Configuration: Tips, FastCap
Item #Nozzle SizeDroplet SizePressure RangeFlow Rate
Item #
LDC90-01
Nozzle Size
01
Droplet Size
M-F
Pressure Range
20-90 PSI (1.5-6 BAR)
Flow Rate
0.07-0.15 GPM (0.23-0.55 LPM)
Item #
LDC90-015
Nozzle Size
015
Droplet Size
M-F
Pressure Range
20-90 PSI (1.5-6 BAR)
Flow Rate
0.11-0.23 GPM (0.42-0.83 LPM)
Item #
LDC120-02
Nozzle Size
02
Droplet Size
C-F
Pressure Range
20-90 PSI (1.5-6 BAR)
Flow Rate
0.15-0.30 GPM (0.56-1.13 LPM)
Item #
LDC120-03
Nozzle Size
03
Droplet Size
C-F
Pressure Range
20-90 PSI (1.5-6 BAR)
Flow Rate
0.22-0.44 GPM (0.84-1.68 LPM)
Item #
LDC120-04
Nozzle Size
04
Droplet Size
C-M
Pressure Range
20-90 PSI (1.5-6 BAR)
Flow Rate
0.30-0.59 GPM (1.12-2.23 LPM)
