IntelliBrite® 5G White LED Pool Lights

Enjoy Pure, White, Energy-efficient Pool Lights

The IntelliBrite 5G white lights combine unmatched energy efficiency with superior light intensity and distribution. The exclusive design can be adjusted to create a standard, wider beam or a narrower pattern, depending on your pool’s needs.*

  • Utilizes less energy than comparable incandescent lights
  • Pool lens can be rotated to 180° to provide wide beam pattern (standard) or narrow beam pattern
  • Compatible with Pentair stainless-steel and plastic niches
  • Available in 120-V and 12-V versions
  • Available in 300-W, 400-W and 500-W incandescent equivalencies

*Appearance of color and white LED light may vary between various models of lights. Appearance and perception of pool lighting may vary depending on a number of factors including, but not limited to, the particular model of light, the location/depth/angle of the light’s installation, pool finish/material, pool depth/shape/geometry, ambient light sources, subjective factors and more. For best results when using multiple lights, use all the same model and do not mix multiple models of lights within a single installation.




/

Eco Select Logo

Product Photos

Product Components

  1. Custom reflector to eliminate hot spots
  2. LED lights for exceptional light intensity
  3. Superior lens geometry to improve color effects
  4. Light beam distribution creates more uniform illumination



Unmatched Energy Efficiency

IntelliBrite 5G white underwater LED lights are not only brighter than incandescent lights, they’re almost 10x more efficient with a pure, white light uses 89% less energy. Their extended service life and energy efficiency can make the savings really add up.

Exceptional Performance

IntelliBrite 5G underwater white LED pool lights deliver superior light intensity and distribution—with no hot spots or glare—and offer pool owners long-lasting durability.



IntelliBrite 5G White LED Lights Video

See more of how the IntelliBrite 5G White LED Pool and Spa Lights can brighten your pool.

Specifications

Item #DescriptionVoltageWattageCord Length (Ft.)Incandescent EquivalencyCarton Qty.Carton Wt. (Lbs.)Color
601100IntelliBrite 5G White Pool Lights - 300 Watt Equivalent, 120 Volt120 VAC40W30300W Equivalency1 White LED
601101IntelliBrite 5G White Pool Lights - 300 Watt Equivalent, 120 Volt120 VAC40W50300W Equivalency1 White LED
601102IntelliBrite 5G White Pool Lights - 300 Watt Equivalent, 120 Volt120 VAC40W100300W Equivalency1 White LED
601103IntelliBrite 5G White Pool Lights - 300 Watt Equivalent, 120 Volt120 VAC40W150300W Equivalency1 White LED
601104IntelliBrite 5G White Pool Lights - 300 Watt Equivalent, 120 Volt120 VAC40W250300W Equivalency1 White LED
601105IntelliBrite 5G White Pool Lights - 300 Watt Equivalent, 12 Volt12 VAC40W30300W Equivalency1 White LED
601106IntelliBrite 5G White Pool Lights - 300 Watt Equivalent, 12 Volt12 VAC40W50300W Equivalency1 White LED
601107IntelliBrite 5G White Pool Lights - 300 Watt Equivalent, 12 Volt12 VAC40W100300W Equivalency1 White LED
601108IntelliBrite 5G White Pool Lights - 300 Watt Equivalent, 12 Volt12 VAC40W150300W Equivalency1 White LED
601200IntelliBrite 5G White Pool Lights - 400 Watt Equivalent, 120 Volt120 VAC48W30400W Equivalency1 White LED
Show more
Item #DescriptionVoltageWattageCord Length (Ft.)Incandescent EquivalencyCarton Qty.Carton Wt. (Lbs.)Color
601100IntelliBrite 5G White Pool Lights - 300 Watt Equivalent, 120 Volt120 VAC40W30300W Equivalency1 White LED
601101IntelliBrite 5G White Pool Lights - 300 Watt Equivalent, 120 Volt120 VAC40W50300W Equivalency1 White LED
601102IntelliBrite 5G White Pool Lights - 300 Watt Equivalent, 120 Volt120 VAC40W100300W Equivalency1 White LED
601103IntelliBrite 5G White Pool Lights - 300 Watt Equivalent, 120 Volt120 VAC40W150300W Equivalency1 White LED
601104IntelliBrite 5G White Pool Lights - 300 Watt Equivalent, 120 Volt120 VAC40W250300W Equivalency1 White LED
601105IntelliBrite 5G White Pool Lights - 300 Watt Equivalent, 12 Volt12 VAC40W30300W Equivalency1 White LED
601106IntelliBrite 5G White Pool Lights - 300 Watt Equivalent, 12 Volt12 VAC40W50300W Equivalency1 White LED
601107IntelliBrite 5G White Pool Lights - 300 Watt Equivalent, 12 Volt12 VAC40W100300W Equivalency1 White LED
601108IntelliBrite 5G White Pool Lights - 300 Watt Equivalent, 12 Volt12 VAC40W150300W Equivalency1 White LED
601200IntelliBrite 5G White Pool Lights - 400 Watt Equivalent, 120 Volt120 VAC48W30400W Equivalency1 White LED
601201IntelliBrite 5G White Pool Lights - 400 Watt Equivalent, 120 Volt120 VAC48W50400W Equivalency1 White LED
601202IntelliBrite 5G White Pool Lights - 400 Watt Equivalent, 120 Volt120 VAC48W100400W Equivalency1 White LED
601203IntelliBrite 5G White Pool Lights - 400 Watt Equivalent, 120 Volt120 VAC48W150400W Equivalency1 White LED
601204IntelliBrite 5G White Pool Lights - 400 Watt Equivalent, 120 Volt120 VAC48W250400W Equivalency1 White LED
601205IntelliBrite 5G White Pool Lights - 400 Watt Equivalent, 12 Volt12 VAC48W30400W Equivalency1 White LED
601206IntelliBrite 5G White Pool Lights - 400 Watt Equivalent, 12 Volt12 VAC48W50400W Equivalency1 White LED
601207IntelliBrite 5G White Pool Lights - 400 Watt Equivalent, 12 Volt12 VAC48W100400W Equivalency1 White LED
601208IntelliBrite 5G White Pool Lights - 400 Watt Equivalent, 12 Volt12 VAC48W150400W Equivalency1 White LED
601300IntelliBrite 5G White Pool Lights - 500 Watt Equivalent, 120 Volt120 VAC55W30500W Equivalency1 White LED
601301IntelliBrite 5G White Pool Lights - 500 Watt Equivalent, 120 Volt120 VAC55W50500W Equivalency1 White LED
601302IntelliBrite 5G White Pool Lights - 500 Watt Equivalent, 120 Volt120 VAC55W100500W Equivalency1 White LED
601303IntelliBrite 5G White Pool Lights - 500 Watt Equivalent, 120 Volt120 VAC55W150500W Equivalency1 White LED
601304IntelliBrite 5G White Pool Lights - 500 Watt Equivalent, 120 Volt120 VAC55W250500W Equivalency1 White LED
601305IntelliBrite 5G White Pool Lights - 500 Watt Equivalent, 12 Volt12 VAC55W30500W Equivalency1 White LED
601306IntelliBrite 5G White Pool Lights - 500 Watt Equivalent, 12 Volt12 VAC55W50500W Equivalency1 White LED
601307IntelliBrite 5G White Pool Lights - 500 Watt Equivalent, 12 Volt12 VAC55W100500W Equivalency1 White LED
601308IntelliBrite 5G White Pool Lights - 500 Watt Equivalent, 12 Volt12 VAC55W150500W Equivalency1 White LED
640140IntelliBrite 5G White Spa Lights - 120 Volt120 VAC18W30100W Equivalency16.5
640141IntelliBrite 5G White Spa Lights - 120 Volt120 VAC18W50100W Equivalency18
640142IntelliBrite 5G White Spa Lights - 120 Volt120 VAC18W100100W Equivalency112
640143IntelliBrite 5G White Spa Lights - 120 Volt120 VAC18W150100W Equivalency116
640144IntelliBrite 5G White Spa Lights - 120 Volt120 VAC18W250100W Equivalency125
640150IntelliBrite 5G White Spa Lights - 12 Volt12 VAC18W30100W Equivalency15.5
640151IntelliBrite 5G White Spa Lights - 12 Volt12 VAC18W50100W Equivalency17
640152IntelliBrite 5G White Spa Lights - 12 Volt12 VAC18W100100W Equivalency111
640153IntelliBrite 5G White Spa Lights - 12 Volt12 VAC18W150100W Equivalency118
Show less

Products beginning with EC- are exclusive to e-commerce sales. For warranty information please visit www.pentair.com/warranty.

Underwater shot of the swimming pool with bubbles

Have Questions About This Product?

We have answers! Visit the Help Center for expert insights from Pentair Pool.

Search the Help Center

All Pentair UL Listed underwater lights are certified for use in freshwater with up to 6,000 ppm salinity.

Warning: The IntelliBrite white LED light cannon be used in a dimmer circuit. Using a dimmer switch will result in permanent damage to the light.

Note: All 120-V pool and spa lights must be connected to a branch circuit.

Notice: Underwriters Laboratories has listed with Pentair Water Pool and Spa Inc. lights for use with Pentair Water Pool and Spa, Pentair Pool Products, American Products, Purex or PacFab niches ONLY. To ensure proper grounding/bonding connections, install only Pentair Water Pool and Spa lights in Pentair Water Pool and Spa, Pentair Pool Products, American Products, Purex or PacFab niches only.

Pentair has a trained team of TradeGrade experts and third-party resources that will be scouring the internet 24/7 for TradeGrade violations. Our guarantee to you is that we will use all resources at our disposal to actively monitor and enforce this policy. If a TradeGrade product is sold online, the warranty will be limited to a 60-day limited warranty. Pentair will not be liable for any costs or expenses related to an extended warranty provided to a customer beyond the 60-day limited warranty that Pentair provides for such sales. Additionally, no PIP dollars will be rewarded to the dealer for the purchase. When a TradeGrade product is purchased and sold in compliance with the TradeGrade policy, that product will receive the full product warranty.
