IntelliCenter® Pool Automation System HUB

There are three offerings in the IntelliCenter family of products:

• IntelliCenter System
• IntelliCenter® Lite System
• IntelliCenter® Upgrade Kit for EasyTouch®/IntelliTouch®

Features are consistent across all IntelliCenter Pool Control System products.

The IntelliCenter system can control up to forty auxiliary circuits. These are defined as High Powered AC Voltage (120VAC & 240VAC) not exceeding three horsepower. This includes the following features:

• pool pumps (single-speed or variable)
• pressure-side cleaner pumps
• feature pumps (single-speed or variable)
• lights (colored or white)
• sanitization equipment (e.g., IntelliChlor® Salt Chlorine Generator)

It also includes thirty-two feature circuits. Examples of what these can control include additional speeds on a variable-speed pump or an actuator to be assigned without using an existing auxiliary circuit.

IntelliCenter can also be set up on the customer’s Internet and controlled remotely via the IntelliCenter2 app.

The IntelliCenter system works in a variety of ways. The IntelliCenter System works with the IntelliCenter2 app and other available control panel options, including a main panel utilizing a full capacity touchscreen, any expansion panel (same screen as main), wired indoor remote (same screen as main), wireless handheld remote (same screen as main), wired spa side remote (push button).

Simply connect IntelliCenter Pool Control System to your home WiFi network (direct wired Ethernet or wireless connection kit), download the app, add your equipment, and start scheduling your desired routines.

Yes! The IntelliCenter System makes programming pool heater settings, lighting adjustments and more easily manageable through the IntelliCenter2 app. The easy-to-use interface allows monitoring or controlling your pool automation system from anywhere in the world.

The IntelliCenter System offers real-time alerts and status information for the main panel, expansion panels and wireless or wired remotes via the IntelliCenter2 app. The system can notify you when attention is needed to address potential issues before they negatively impact your pool or equipment.

In addition to making it easy to automate your pool schedule, the IntelliCenter System also provides you with information on your equipment’s performance. This information can help you make any adjustments needed to optimize the efficiency and performance of equipment, which can help reduce operating costs and maintenance.

IntelliCenter Pool Control System is the flagship automation system for Pentair and continues to make ongoing improvements. A lower-priced entry point is now available to meet market needs, and new SKUs are available.

The new IntelliCenter Lite System SKUs include a power center rather than a load center with a 125AMP breaker bus. Two IntelliCenter Lite SKUs exclude a high-power wireless kit used to connect to the pool owner’s router wirelessly. With these two options, remote access can be provided with a hard-wired cat-5 Ethernet connection from the customer’s main network router directly into the back of the IntelliCenter main board. The new SKUs are used when a load center and breaker panel are not needed or a wireless connection to the pool owner’s router is not required.

IntelliCenter Lite bundles do not include water chemistry solutions currently. You can order an IntelliChlor® Salt Chlorine Generator and other water chemistry products separately.

The new SKUs for the IntelliCenter system are as follows:

PART NUMBER - DESCRIPTION

523623 - IntelliCenter® Lite System (Power Center with i5P Personality Kit)
523624 - IntelliCenter® Lite System (Power Center with i5PS Personality Kit and two standard valve actuators)
523625 - IntelliCenter® Lite System (Power Center with i5PS Personality Kit and two IntelliValve® Actuators)
523668 - IntelliCenter® Lite System (Power Center power center with i5P Personality Kit) without High Power Wireless Link
523669 - IntelliCenter® Lite System (Power Center power center with i5PS Personality Kit) without High Power Wireless Link

The IntelliCenter Lite system has the same functionality as the IntelliCenter Pool Control System.

The IntelliCenter Lite system is an expandable automation system with the same functionality as an IntelliCenter system. It has significantly more capability than the EasyTouch® Lite system. However, the following table provides the closest equivalents to the EasyTouch Lite system:

PART NUMBER - APPLICATION - EASYTOUCH LITE MAPPING

523623
5 Relay, Pool Only System, No Breaker Panel
522353 - EASYTOUCH PL4 CONTROL SYSTEM W/SL (with ScreenLogic®)
Note: IntelliCenter Lite includes one additional relay and IntelliCenter features

523624
5 Relay, Pool & Spa System with Compool® Actuators, No Breaker Panel
522355 - EASYTOUCH PSL4 CONTROL SYSTEM W/SL (with ScreenLogic and two valve actuators)
Note: IntelliCenter Lite includes one additional relay and IntelliCenter features

523625
5 Relay, Pool & Spa System with IntelliValve Actuators, No Breaker Panel
N/A

523668
5 Relay, Pool Only System, No Breaker Panel, No Wireless Link (remote access via Ethernet)
522352 - EASYTOUCH PL4 CONTROL SYSTEM
Note: IntelliCenter Lite includes one additional relay, IntelliCenter features and remote access via Ethernet

523669
5 Relay, Pool & Spa System, No Breaker Panel, No Wireless Link (remote access via Ethernet)
522354 - EASYTOUCH PSL4 CONTROL SYSTEM
Note: IntelliCenter Lite includes one additional relay, IntelliCenter features and remote access via Ethernet

The IntelliCenter Lite system SKUs availability is as follows:

PART NUMBER - DESCRIPTION - AVAILABILITY

523623 - IntelliCenter® Lite System (Power Center with i5P Personality Kit)
1/2023

523624 - IntelliCenter® Lite System (Power Center with i5PS Personality Kit and two standard valve actuators)
1/2023

523625 - IntelliCenter® Lite System (Power Center with i5PS Personality Kit and two IntelliValve® Actuators)
1/2023

523668 - IntelliCenter® Lite System (Power Center with i5P Personality Kit) without High Power Wireless Link
3/2023

523669 - IntelliCenter® Lite System (Power Center with i5PS Personality Kit) without High Power Wireless Link
3/2023

The IntelliCenter Lite system provides significantly more functionality than the EasyTouch Lite system and is much easier to set up, configure and operate, saving valuable time. A brief feature comparison follows:

EASYTOUCH LITE - EASYTOUCH - INTELLICENTER

FOUR RELAYS (FILTER PUMP + THREE PIECES OF EQUIPMENT)
Up to eight relays
40 relays (up to three expansion enclosures)

ONE FILTER PUMP
Up to two IntelliFlo® pumps
16 IntelliFlo pumps

TWO FEATURE CIRCUITS
Up to eight feature circuits
32 feature circuits and 16 groups

FOUR SCHEDULES
Up to 12 schedules/programs
100 multifunction schedules/programs

TWO BODIES OF WATER
Two bodies of water
Two bodies of water (multiple bodies on product roadmap)

Additional IntelliCenter system features include a setup wizard to walk you through system setup and configuration, Over-the-air (OTA) software updates, and the capability to store and load commonly used system configurations.

If you have additional questions about the IntelliCenter or IntelliCenter Lite systems, please contact our sales team or Pentair customer service at 1-800-831-7133.

• July 31, 2023 for all IntelliTouch Systems
• September 29, 2023 for all EasyTouch Systems

Orders for IntelliTouch and/or EasyTouch systems purchased before the sale dates of July 31 and September 29, 2023, respectively, will be honored as available.

Communications will be sent to dealers in early April 2023 and should take immediate effect.

Transitioning customers to the IntelliCenter system:

• Help build consumer goodwill knowing they have the most up-to-date system and modern pool automation features Pentair offers.
• Offers the most updated Pentair user experience.
• Supports remote monitoring services allowing service providers to offer more effortless pool maintenance.
• Offers enhanced network availability.
• Access to continued advancements in mobile apps, remote monitoring portals, and firmware developments.

For any EasyTouch or IntelliTouch product purchased in 2023, the standard Pentair manufacturer warranty policy applies to the following:

• Warranty start date based on the installation date
• One-year-term if purchased as standalone
• Three-year-term if the product was purchased in a bundle

We will replace legacy systems with comparable replacement equipment while parts are available. If parts are unavailable, we will provide the appropriate IntelliCenter Upgrade Kit.

The customer service agent may direct the customer to a Pentair agent for ordering instructions or to local dealer installers for assistance with a suitable solution or comparable product to keep their system functioning may be required.

Pentair customer service agents may, on a discretionary basis, offer an IntelliCenter upgrade kit at zero cost. Goodwill courtesy is promoted in warranted situations.
